Characteristic:
1. Mitsubishi PLC main control, led touch screen data input and display, simple and flexible operation.
2. It can change the crankshaft of various diameter at will,.
3. Double axis exchange winding, faster speed and higher efficiency. Magnetic powder unwinding control.
4. Magnetic powder clutch or servo motor winding can be selected, and winding is smooth.
5. Using patent technology, rotating automatic inflation (non-traditional contact inflation), easy to control, long service life
6. Equipped with conveying roller and anti sticking cot, it can be used for rewinding materials with or without glue
7. The discharging machine is separated from the main machine, and the discharging machine can correct the deviation automatically

Main technical parameters

Machine specifications	1300mm   1600mm
Effective width	1300mm   1600mm
Mechanical speed	0--200m/min
Maximum unwinding diameter	800mm
Maximum winding diameter	250mm
Reel size	25.4mm/38mm/76.2mm（Exchangeable）
Main engine power	4KW
Supply voltage	380V   50HZ 3Ф
Working pressure	0.4-0.6MPa
Dimensions	2780*1610*1400mm
