Xq-1300 belt coater

Belt machine, sealing belt machine, transparent belt machine, multifunctional belt machine
Hotline:13761127036

Product details

Product function:
The tape machine can produce conventional dry tape, all kinds of wide and narrow tape, transparent tape, color tape, printing tape, etc. The belt conveyor of our company adopts electric, coal and gas three drying integration, electronic temperature control, stepless speed change, automatic counting, automatic deviation correction, gravure printing, advanced infrared heating, cooling and re pressing and other high-tech. The production processes of collecting and discharging, printing, coating, drying, hot air circulation, traction, slitting and winding are completed in one machine. Quickly pick up the phone next to order it!

Product introduction:
BOPP film coater is a kind of machine and equipment for coating BOPP sealing tape, which can automatically break cloth at high speed.
Base material: BOPP film
Coating method: comma scraper matching coating and steel wire scraper coating.
Purpose: used for coating BOPP sealing tape.

General features:
Discharging mode: high speed automatic cloth breaking, automatic film splicing, automatic edge correction;
Reeling mode: comma type gluing, stable equipment, uniform gluing;
Drying methods: steam heating, hot air heating, electric heating, heavy oil heating, etc;
The temperature is controlled by stages, and can be adjusted according to the process requirements;
The drying efficiency is high by using narrow slot nozzle to dry in oven;
Drive part: AC motor drive, frequency converter speed control;
Tension control: automatic tension control;
Data processing: all data input adopts man-machine interface LCD touch screen mode, central controller PLC processing, programming operation;
